Overview
Black 6" single wall stove pipe for the visible run from your wood stove up to the ceiling or wall.
Straight sections in five fixed lengths so you can build the exact run you need. Each section is 21 gauge steel finished in high-temperature black paint; one pipe section is included per order. Fixed lengths cannot be cut down, so use a telescoping section to fine-tune the height.
Single wall stove pipe is the exposed connector between your stove and the chimney. The run goes stove flue collar → stove adapter → single wall pipe, elbows and telescoping sections → stove pipe adapter at the ceiling support box or wall thimble, where the insulated Class A chimney starts and carries the smoke through the ceiling, roof or wall.
Specifications
| Spec | Value |
|---|---|
| Inside diameter | 6" |
| Material | 21 gauge steel, high-temperature black paint |
| Clearance to combustibles | 18" |
| Use | Indoor only |
| Lengths | 12", 18", 24", 36", 48" (fixed, cannot be cut) |
Fits wood stoves with a 6" flue collar, including our wood stoves.
Clearance: ComfortBilt specifies 18" clearance to combustibles (walls, ceilings, wood mantels, etc.) for AllFuelHST single wall pipe. That is far more than insulated Class A chimney needs, which is why single wall pipe must stop at the ceiling support box or wall thimble and never pass through a wall or ceiling itself. Indoor use only.
System note: The AllFuelHST stove pipe adapter and AllFuelHST Class A chimney parts connect only to other AllFuelHST parts. Use the AllFuelHST adapter to join this pipe to an AllFuelHST 6" chimney.
Also needed
- AllFuelHST 6" single wall stove adapter
- AllFuelHST 6" telescoping single wall stove pipe
- AllFuelHST 6" single wall 45° / 90° elbows
- AllFuelHST 6" stove pipe adapter to Class A chimney
- AllFuelHST 6" Class A ceiling support box
- AllFuelHST 6" Class A wall thimble
- AllFuelHST 6" Class A chimney pipe
- Class A chimney pipe and ceiling support boxes
